German manufactured range of silage harvesting, feeding and manure spreading machinery for Dairy, Beef and general livestock in Australia.

Strautmann Livestock Machinery

Feed out Wagon



Strautmann Verti Mix Double Auger Self-Propelled Mixer Wagon

Photograph for illustration purposes - standard specifications may not match those shown.

FEATURES OF THE FVW FEED-OUT WAGON

CONSTRUCTION

  • Solid robust construction designed for highest long term demands
  • High tensile floor chains, 13mm 21 ton braking point
  • Automatic floor chain tensioning
  • Bolted side wall construction
  • Single axles with braking
  • Large floatation tyres
  • Draw bar ring hitch
  • PTO shaft cam-type, cut out clutch on side wide angle
  • Lighting – stop, tail and indicators

FEED-OUT

  • Beaters with aggressive rip tynes can also process dense and longer silage
  • Very good mixing effect when loaded in layers
  • Hydraulic driven cross conveyor that can feed-out right or left as required
  • Hydraulic driven moving floor with speed control

CONTROLS

  • Simple and convenient operation of all control functions via Bowden cables from the tractor

OPTIONS

  • Weighing system
  • Tandem axle with braking

SPECIFICATIONS

FVW 100
FVW 120
FVW 140
FVW 160
Length (m)
6.50
7.30
6.50
7.30
Width (m)
2.30
2.30
2.30
2.30
Height on standard wheels (m)
2.32
2.45
2.95
2.95
Capacity (m3)
10.00
12.00
14.00
16.00
Gross weight (kg)
6,900
7,800
8,000
8,000
Empty weight (kg)
2,660
2,960
3,160
3,360
Single Axle
15.0/
70-18
15.0/
70-18
15.0/
70-18
15.0/
70-18
Beaters
2
2
3
3
PTO Speed (rpm)
540
540
540
540
Power Requirement (kW)
30
37
37
37
Power Requirement (hp)
40
50
50
50

BROCHURE

Click this link to download a brochure.
Please note that Australian specifications may vary to those shown on the manufacturer's brochure and website.
Follow this link to the  manufacturer's website (Strautmann)

Disclaimer: Specifications and features described on the website are subject to change without notice. All care has been taken to present accurate information, however, the company is not liable for unintended errors or omissions.
* Tandem axle is standard
